ABC Powder Cartridge Type Portable Fire Extinguishers
Ceasefire’s ABC Powder Based Portable Extinguishers (Spot Pressure Type) are built for speed, power and reliability. A simple two-step activation mechanism allows you to fight the fire within seconds. MAP50 concentrations of Mono Ammonium Phosphate maximises the fire fighting power available to you. And stringent quality control and multiple point testing systems ensure that when you are faced with a fire, these extinguishers will deliver.
The cartridge type technology makes the extinguishers highly safe for all types of spaces as the pressure is created only at the time of fire fighting. Ceasefire’s ABC Powder Based Portable Extinguishers (Spot Pressure Type) come in 4Kg, 6Kg, 9 Kg and 12 Kg size variants.
Fire Ratings:
MAP-50
4 Kg
6 Kg
9 Kg
12 Kg
IS 15683
4A, 144B
6A, 183B
6A, 233B
-
EN-3
-
-
-
55A, 233B
-
Classification: Fights Class A, B, C as well as Electrically started fire.
-
Easy-to-use with Quick Activation: Being a spot pressure extinguisher, the Cartridge can be instantly activated by firmly pressing the trigger.
-
Agent Potency: Packed with 50% MAP concentration.
-
Pressure gauge: Easy-to-read pressure gauge for ease of monitoring.
-
Easy Refilling: Unlike conventional extinguishers, these extinguishers can be refilled immediately anywhere, thus eliminating the downtime needed to take them to and fro from the factory.
-
10-year Warranty: 10-year Warranty means Ceasefire is looking out for the health of your fire safety products.
-
Certification: BIS, LPCB, and PED certified.
What’s New
01. Screen-Printed Cylinder Label
Built to last.
Product information is screen-printed directly onto the cylinder for excellent resistance to weather conditions, tampering, scratching, rubbing, chemicals and fading- keeping critical information long lasting.02. Glow-in-the-Dark Signage
Find it when visibility is low.
A phosphorescent locator sign at the base helps identify the extinguisher in darkness, low visibility and smoke, enabling faster access during emergencies. Conforms to DIN standards and exceeds DIN 67510 Part 4 requirements.03. Eco-Friendly Packaging
Less packaging waste. More responsibility.
Recyclable paper, corrugated board and natural rubber replace conventional packaging materials, helping reduce carbon footprints and making recycling easier.-
GLOSSARY MAP-50 Fire-Extinguisher Cartridge Type – 4kg MAP-50 Fire-Extinguisher Cartridge Type – 6kg MAP-50 Fire-Extinguisher Cartridge Type – 9kg Product Code CF-001151 CF-001152 CF-001153 Capacity of Agent 4
(Kg)6
(Kg)9
(Kg)Filling Tolerance By Mass ± 2
(%)± 2
(%)± 2
(%)Agent ABC Powder MAP 50 ABC Powder MAP 50 ABC Powder MAP 50 Certification Standard ISO 9001, IS-15683, PED ISO 9001, IS-15683, PED ISO 9001, IS-15683, PED VALVE Material of Construction (MOC) Brass Brass Brass VALVE Construction Forging and machining Forging and machining Forging and machining SHELL Material of Construction (MOC) Steel CR2 (DC01) Steel CR2 (DC01) Steel CR2 (DC01) SHELL Construction Deep Drawn & MIG Welded Deep Drawn & MIG Welded Deep Drawn & MIG Welded Min. Wall Thickness 1.2
(mm)1.4
(mm)1.4
(mm)Diameter of Shell (approx.) 140
(mm)160
(mm)175
(mm)Total Height (approx.) 465
(mm)510
(mm)635
(mm)Test Pressure 35
(Bar)35
(Bar)35
(Bar)Anti-corrosive Treatment External Outer surfaces were EP Powder coated having Min. Thickness 50 Micron Shade 536/538 Of IS-5 Outer surfaces were EP Powder coated having Min. Thickness 50 Micron Shade 536/538 Of IS-5 Outer surfaces were EP Powder coated having Min. Thickness 50 Micron Shade 536/538 Of IS-5 Service Pressure 13
(Bar)13
(Bar)15
(Bar)Type of Operating Mechanism Squeeze Grip Squeeze Grip Squeeze Grip MOC and Length of Hose EPDM Rubber Braided Hose Pipe with nozzle min. Length of Flexible Portion Of Hose 400 mm
(mm)EPDM Rubber Braided Hose Pipe with nozzle min. Length of Flexible Portion Of Hose 400 mm
(mm)EPDM Rubber Braided Hose Pipe with nozzle min. Length of Flexible Portion Of Hose 650 mm
(mm)Cartridge Size 90
(grm)120
(grm)250
(grm)Minimum Throw Distance (BRD as per IS-15683) > 2
(Meter)> 2
(Meter)> 2
(Meter)Min. Discharge Time (as per IS-15683) 15
(Sec.)15
(Sec.)15
(Sec.)Applicable to Type of Fire A, B, C, & Electrical Started Fire A, B, C, & Electrical Started Fire A, B, C, & Electrical Started Fire Fire Rating 4A | 144B 6A | 183B 6A | 233B Operating Temperature Range From -30 to +60
(°C)From -30 to +60
(°C)From -30 to +60
(°C)Extinguisher Label Screen printed Screen printed Screen printed Glow in the Dark Fire Extinguisher Locator Yes Yes Yes Green Packaging (Environment Friendly) Yes Yes Yes Gross Weight* 7.80 to 8.10
(Kg)10.60 to 11.0
(Kg)15.40 to 15.80
(Kg)Product Warranty** 10
(Year)10
(Year)10
(Year)MOUNTING Bracket J hanger J hanger J hanger *It includes Empty Extinguisher, Contents, Plastic Base, Hose / Horn and bracket
**The warranty is subject to the terms and conditions mentioned on the warranty card.
