EN APPROVED WATERMIST, FOAMMIST & GREENFOAMMIST WHEELED EXTINGUISHERS
Named after the four state-of-the-art Multi-Rotors working in sync in each container, the Ceasefire Quad brings together the efficiency of a fire extinguisher with the power of a hydrant system – without the drawbacks.
Harnessing water's immense cooling powers and multiplying them hundreds of times over, Ceasefire Quad breaks water down into a fine mist of under 80 microns. This mist is then thrown at the fire with a great kinetic force, covering a large surface area. As soon as the mist comes into contact with the fire, it instantly turns into steam. Enveloping the flames, cutting down the oxygen supply and reducing temperature to below combustion levels.
The Quad's Multi-Rotors, located within the mist generator, work in tandem, mixing water and air in a pre-set proportion to generate Watermist in the specially designed discharge gun. Thereby increasing the power of water by 400 times.
Meant for areas where fire risk is huge, or where large amounts of combustible materials are stored, the trolley-mounted Quad can be taken anywhere with ease.
It is also an ideal extinguisher for closed environments, where unlike powder and other extinguishers, it doesn’t lose firefighting power. That’s cutting-edge technology at the very forefront.
Equipped with four Multi-Rotors in each container, it's fully capable of generating Watermist quickly and efficiently. Available in 25 Ltrs., 50 Ltrs., and 100 Ltrs, in Stainless Steel the Quad truly is a fire engine on wheels.
FIRE RATINGS:
Agent & Sizes
25 Ltr
50 Ltr
100 Ltr
Green Foam mist
A, IIB
A, IVB
A, IVB
Foam mist
A, IVB
A, IVB
A, IVB
Water mist
A
A
A
-
Application: Fights Class A, B, C, F, and electrical fires. (May vary for different models of Quad)
-
Water Efficient: Specially designed nozzles that convert water into a fine mist with minuscule droplets that increase the coverage of water in the fire zone.
-
Solid stainless steel body: Its solid stainless steel body can withstand high temperatures.
-
Easy to use with quick activation: Being a stored pressure extinguisher it’s always ready to use.
-
Pressure gauge: Easy-to-read pressure gauge for ease of monitoring.
-
Reduces damage: Uses filtered water, eliminating collateral damage.
-
Environment friendly: The use of distilled water in combination with cutting-edge technology ensures this extinguisher has no negative impact on the environment.
-
5 years Warranty: The 5 years Warranty means Ceasefire is looking out for the health of your fire safety products.
-
Certification: LPCB, BSI Kitemark, PED, MED, and UKCA-MED certified (May vary for individual models).
-
GLOSSARY FIRE EXT WATER MIST 25L SS SINGLE TROLLEY SP RED (QUAD) FIRE EXT WATER MIST 50L SS SINGLE TROLLEY SP RED (QUAD) FIRE EXT WATER MIST 100L SS SINGLE TROLLEY SP RED (QUAD) PRODUCT CODE CF-000741 CF-000742 CF-000743 AGENT WATER WATER WATER THROW 4 METERS 4 METERS 4 METERS CERTIFICATION OR VERIFING BODY LPCB,BSI, EUROCERT,BRE GLOBAL LPCB,BSI, EUROCERT,BRE GLOBAL LPCB,BSI, EUROCERT,BRE GLOBAL CERTIFICATION TYPE EN1866, PED,MED, UK MED EN1866, PED,MED, UK MED EN1866, PED,MED, UK MED LPCB MARKING YES YES YES KITEMARK MARKING YES YES YES CE MARKING YES YES YES MED/WHEEL MARKING YES YES YES UK MED MARKING YES YES YES GROSS WEIGHT 65.00 KG 106.80 KG 166.20 KG NET CONTENTS 23.75 TO 25.00 LTR 47.50 TO 50.00 LTR 95.00 TO 100.00 LTR APPROX. HEIGHT OF FIRE EXT. 1075 MM 1200 MM 1615 MM DISCHARGE MECHANISM OPERATING LEVER (BALL VALVE) OPERATING LEVER (BALL VALVE) OPERATING LEVER (BALL VALVE) APPLICABLE ON FIRES CLASS A & ELECTRICAL STARTED FIRE CLASS A & ELECTRICAL STARTED FIRE CLASS A & ELECTRICAL STARTED FIRE EN 1866 RATINGS A A A CAN CONSTRUCTION DRAWN ROLLED AND MIG WELDED DRAWN ROLLED AND MIG WELDED DRAWN ROLLED AND MIG WELDED VALVE / CAP CONSTRUCTION FORGING AND MACHINING FORGING AND MACHINING FORGING AND MACHINING EXTERNAL COATING EPOXY POLYESTER POWDER COATING EPOXY POLYESTER POWDER COATING EPOXY POLYESTER POWDER COATING WARRANTY IN YEAR 5 5 5 G.A. DRAWING NUMBER CF/SP-WM25/GA/01 CF/SP-WM50/GA/01 CF/SP-WM100/GA/01 WORKING PRESSURE 15BAR 15BAR 15BAR DIA. OF SHELL (OD) 300.0 MM 350.0 MM 400.0 MM OPERATING TEMPERATURE 5OC TO +60OC 5OC TO +60OC 5OC TO +60OC HYDROSTATIC TEST PRESSURE 30BAR 30BAR 30BAR CYLINDER MATERIAL SPEC. SS 304 (1.4301) SS 304 (1.4301) SS 304 (1.4301) BODY THICKNESS 1.8 MM 2.0 MM 2.0 MM GLOSSARY FIRE EXT FOAM MIST 25L SS JET SP RED (QUAD) FIRE EXT FOAM MIST 50L SS JET SP RED (QUAD) FIRE EXT FOAM MIST 100L SS JET SP RED (QUAD) PRODUCT CODE CF-000744 CF-000745 CF-000746 AGENT 1% OF TELISOVE 1 % 1% OF TELISOVE 1 % 1% OF TELISOVE 1 % THROW 10 METERS 10 METERS 10 METERS CERTIFICATION OR VERIFING BODY LPCB,BSI, EUROCERT,BRE GLOBAL LPCB,BSI, EUROCERT,BRE GLOBAL LPCB,BSI, EUROCERT,BRE GLOBAL CERTIFICATION TYPE EN1866, PED,MED, UK MED EN1866, PED,MED, UK MED EN1866, PED,MED, UK MED LPCB MARKING YES YES YES KITEMARK MARKING YES YES YES CE MARKING YES YES YES MED/WHEEL MARKING YES YES YES UK MED MARKING YES YES YES GROSS WEIGHT 66.50 KG 107.50 KG 166.70 KG NET CONTENTS 23.75 TO 25.00 LTR 47.50 TO 50.00 LTR 95.00 TO 100.00 LTR APPROX. HEIGHT OF FIRE EXT. 1075 MM 1200 MM 1615 MM DISCHARGE MECHANISM OPERATING LEVER (BALL VALVE) OPERATING LEVER (BALL VALVE) OPERATING LEVER (BALL VALVE) APPLICABLE ON FIRES CLASS A, B & ELECTRICAL STARTED FIRE CLASS A, B & ELECTRICAL STARTED FIRE CLASS A, B & ELECTRICAL STARTED FIRE EN 1866 RATINGS A, IVB A, IVB A, IVB CAN CONSTRUCTION DRAWN ROLLED AND MIG WELDED DRAWN ROLLED AND MIG WELDED DRAWN ROLLED AND MIG WELDED VALVE / CAP CONSTRUCTION FORGING AND MACHINING FORGING AND MACHINING FORGING AND MACHINING EXTERNAL COATING EPOXY POLYESTER POWDER COATING EPOXY POLYESTER POWDER COATING EPOXY POLYESTER POWDER COATING WARRANTY IN YEAR 5 5 5 G.A. DRAWING NUMBER CF/SP-FM25/GA/01 CF/SP-FM50/GA/01 CF/SP-FM100/GA/01 WORKING PRESSURE 15BAR 15BAR 15BAR DIA. OF SHELL (OD) 300.0 MM 350.0 MM 400.0 MM OPERATING TEMPERATURE 5OC TO +60OC 5OC TO +60OC 5OC TO +60OC HYDROSTATIC TEST PRESSURE 30BAR 30BAR 30BAR CYLINDER MATERIAL SPEC. SS 304 (1.4301) SS 304 (1.4301) SS 304 (1.4301) BODY THICKNESS 1.8 MM 2.0 MM 2.0 MM GLOSSARY FIRE EXT GREEN FOAM MIST 25L SS SP RED FIRE EXT GREEN FOAM MIST 50L SS SP RED FIRE EXT GREEN FOAM MIST 100L SS SP RED PRODUCT CODE CF-000750 CF-000751 CF-000752 AGENT 0.5% OF TELISOVE 1 % 0.5% OF TELISOVE 1 % 0.5% OF TELISOVE 1 % THROW 10 METERS 10 METERS 10 METERS CERTIFICATION OR VERIFING BODY LPCB,BSI, EUROCERT LPCB,BSI, EUROCERT LPCB,BSI, EUROCERT CERTIFICATION TYPE EN1866, PED EN1866, PED EN1866, PED LPCB MARKING YES YES YES KITEMARK MARKING YES YES YES CE MARKING YES YES YES GROSS WEIGHT (APPROX) 66.50 KG 107.50 KG 166.70 KG NET CONTENTS 23.75 TO 25.00 LTR 47.50 TO 50.00 LTR 95.00 TO 100.00 LTR APPROX. HEIGHT OF FIRE EXT. 1075 MM 1200 MM 1615 MM DISCHARGE MECHANISM OPERATING LEVER (BALL VALVE) OPERATING LEVER (BALL VALVE) OPERATING LEVER (BALL VALVE) APPLICABLE ON FIRES CLASS A, B & ELECTRICAL STARTED FIRE CLASS A, B & ELECTRICAL STARTED FIRE CLASS A, B & ELECTRICAL STARTED FIRE EN 1866 RATINGS A, IB A, IVB A, IVB CAN CONSTRUCTION DRAWN ROLLED AND MIG WELDED DRAWN ROLLED AND MIG WELDED DRAWN ROLLED AND MIG WELDED VALVE / CAP CONSTRUCTION FORGING AND MACHINING FORGING AND MACHINING FORGING AND MACHINING EXTERNAL COATING EPOXY POLYESTER POWDER COATING EPOXY POLYESTER POWDER COATING EPOXY POLYESTER POWDER COATING WARRANTY IN YEAR 5 5 5 G.A. DRAWING NUMBER CF/SP-GFM25/GA/01 CF/SP-GFM50/GA/01 CF/SP-GFM100/GA/01 WORKING PRESSURE 15BAR 15BAR 15BAR DIA. OF SHELL (OD) 300.0 MM 350.0 MM 400.0 MM OPERATING TEMPERATURE 5OC TO +60OC 5OC TO +60OC 5OC TO +60OC HYDROSTATIC TEST PRESSURE 30BAR 30BAR 30BAR CYLINDER MATERIAL SPEC. SS 304 (1.4301) SS 304 (1.4301) SS 304 (1.4301) BODY THICKNESS 1.8 MM 2.0 MM 2.0 MM
