Large-Remote-Display-Terminal- Fault-Tolerant (TI-002323-FT)
- The RCT has additional sector based control keys for Silence, Mute, Resound and Reset, which allows other networked panels to selectively respond to controls as programmed. E.g. on a site with multiple buildings, a user may be allowed to silence and reset fires originating in their own building.Fires originating from other buildings are displayed but cannot be reset.
- Fully on-site programmable via onboard alphanumeric keypad or PC configuration tools.
- View all information from across the network
- By using flash memory and an advanced graphical display the remote terminals can be easily configured to operate in virtually any language, with any character set and allows for the installer’s logo and company details to be displayed on the LCD display during normal operation.
- Fully programmable push buttons for remote isolation, class change or general alarms. compatible with a wide range of routing equipment.
- Networked for System Display or Control
- Programmable switch input
- Graphical LCD display
- Intelli-Sense-NeT compatible
- Slide-in labels
- Small, robust and compact
- 24V DC operating voltage
- Disable/enable options
- 1-year warranty
1 Type Networkable 2 Model TI-002323-FT 3 Display White backlit 240x64 graphical LCD 4 LED Indicators 2 red (1 x Fire, 1 x Alarm), 1 green (Power) & 18 amber (Fault & System) 5 Keypads Alpha numeric keypad, navigation keys & on-board buzzer mute facility 6 Controls System keys for Mute, Reset, Silence, Resound 7 Key-Switch Input Optional level 2 access enable key switch 8 Power Supply Input 24 VDC, 115mA (/FT: 150mA) operating range 15-30V 9 External Supply Monitoring Monitored external fault input 10 Number of Fire Zones 2000 11 USB/Serial Ports 1 x USB & 1 x RS232 12 Programming Via on-board keypad or PC running Windows tools 13 Enclosure Steel IP30 14 Cable Entry 20mm knock-outs.4 x top and 4 x rear 15 Colour RAL7035 16 Metal work Options Semi flushing bezel, special finishes including Stainless & Chrome 17 Networking On-board Fault-Tolerant network card (TI-002324). Brochure Price List Datasheets Manuals
